In the US, CCW is the norm, but in Europe, CW is standard.
CW /CCW – Clockwise or counter-clockwise turn of the turret. BDC II – Exposed 100-click single-turn elevation/windage locking dials with zero stop/zero click (Polar, Exos, and Stratos hunting lines). BDC H – Exposed 32-click single-turn elevation dial with zero stop (Klassic and Zenith hunting lines). CT – Capped turret (may refer to windage-only or both elevation and windage). SZC – Sub-Zero click (pronounced clicks when dialing below zero on the elevation turret). ZC – Zero click windage turret (pronounced click at zero). Because current PM II scopes with MTC turrets always also have LT and ZC, I omit those codes from the product descriptions. #SCHMIDT BENDER 1 4 FULL#
MTC/LT/ZC – More Tacticle Clicks (pronounced clicks at full MRAD values on the elevation dial), Locking Turrets, and Zero Click (windage has pronounced click at zero).
ST II-B – Generation II single-turn ballistic elevation turret with six movable indicators to indicated distances (new 2020 on select hunting scopes). MT II – Generation II Multi-turn elevation turret (may dial the full available internal travel, new 2020). DT II – Generation II double-turn elevation turret (new 2020). ST II – Generation II single-turn elevation turret (new 2020). MT – Multi-turn elevation turret (may dial the full available internal travel). The following feature codes will help you decipher the Schmidt & Bender Part Number listing: I recommend you determine the Part Number for a scope before placing an order. Part Numbers are very helpful when ordering to ensure you are getting the particular scope model, turret features, and reticle you desire. On the Schmidt & Bender website, the product pages do not list Part Numbers - you must refer to the catalogs for Part Numbers. 2020 Schmidt Bender Catalog - Hunting turrets Schmidt & Bender catalogs and Part Numbers for 20 New in 2020 on the 3-21x40 Exos, Schmidt & Bender offers the new PMII Generation II single-turn turret without MTC (ST II), and a BDC-version of the ST II turret (ST II-B) that features six moveable indicators that can be easily preset to desired range distances using your own ballistic data. In the hunting lines with capped turrets, they've dropped the option for Classic turret adjustments, and now only offer Posicon turret adjustments. The 2020 Schmidt Bender Catalog - Generation II turrets That is, in addition to locking, Generation II elevation turrets allow you to turn MTC on or off. The Generation II elevation turrets feature a lever with three modes: locking, unlocked with MTC, and unlocked without MTC (MTC is the More Tacticle Clicks feature with more pronounced clicks on every tenth click). Schmidt & Bender has introduced new Generation II turret options for select PMII rifle scopes (and the 3-21x40 Exos hunting scope). The GR2ID FFP reticle and GenIIXR FFP reticle are two new reticles for select PMII rifle scopes that appear for the first time in the 2020 catalog: GR2ID FFP GenIIXR FFP #SCHMIDT BENDER 1 4 PDF#
Detailed reticle diagram PDF files are now available on Schmidt & Bender's website product pages: pick a scope, click the reticles tab, then click the reticle for a PDF containing subtension diagrams and reticle images for minimum and maximum magnification for that particular scope model. In the product listings below, see reticles labeled "(new 2020)" or "(discontinued 2020)". Many reticle options have been eliminated, and several new reticles have been introduced. Schmidt & Bender has not introduced any new rifle scope models in 2020, but they updated and significantly streamlined their reticle offerings. Schmidt & Bender scopes are manufactured in Germany and Hungary. The Schmidt & Bender warranty is limited to two years (PM II) or ten years (hunting lines). This post is a list of all Schmidt & Bender rifle scopes on a single page, with available reticles, street prices, features, and links to official product pages, merchants, and reviews.
Field Target scope with 12.Schmidt & Bender is widely considered the benchmark for "alpha-tier" rifle scopes. The additionally magnified field of view and the excellent optics quality make the scope an absolute highlight. The distance scale is absolutely temperature-stable: measurement deviations at a distance are less than 2%.
Thanks to its 34-mm tube, the double turn (now installed standard), and the magnetically clipped and easily removable side wheel, it is perfectly suited for other types of long-distance shooting sports.
The redesigned version of our Field Target scope provides even more precise measurement of distances from 9 m to infinity.
